# config firewall address
(address) # show   <-- check all address configuration
(address) # end

# config firewall address
(address) # edit "test1"
(address) # show     <- check
(address) # abort    <- End and discard last config

# config firewall address
(address) # edit "test1"
(address) # show    <- check
(address) # set subnet 192.168.0.5 255.255.255.0
(address) # show   <- check
(address) # end   <- End and save last config.

config firewall address
  edit "test-server-10"
    set associated-interface "vlan10"
    set subnet 192.168.0.5 255.255.255.0
end

Policy Operation

#config firewall policy
(policy)# show    <- show all policy
(policy)# end
#

#config firewall policy
(policy)# edit 555
(policy)# show
(policy)# abort   <- End and discard last config
#

config firewall policy
  edit 555
    set name "test"
    set srcintf "vlan10"
    set dstintf "port 5"
    set srcadr "xxxx"  "xxxx"  "xxx"
    set action accept
    set schedule "always"
    set servie "HTTP" "ICMP_ANY"
end    <- End and save last config.

delete command

How to delete Policy

# config firwall policy
# delete 1
# end

How to delete router

# config router static
# delete 1
# end

Frotigate Execute Commands

Help	# ?
ping	# execute ping 192.168.0.1
traceroute	# execute traceroute 192.168.1.1
telnet	# execute telnet 192.168.0.10 # execute telnet 192.168.0.1 22
ssh	# execute ssh user@192.168.0.10 # execute ssh user@192.168.0.10 23
execute command like tcpdump	# diagnose sniffer packet port15 ← Interface Port15 # diagnose sniffer packet any 'host xx.xx.xx.xx' # diagnose sniffer packet port15 'host xx.xx.xx.xx' # diagnose sniffer packet any 'host xx.xx.xx.xx or host yy.yy.yy.yy' # diagnose sniffer packet any 'udp port 53 or tcp port 53' # diagnose sniffer packet any 'host xx.xx.xx.xx and tcp port 80'
shutdown	# execute shutdown
clear arp table	# execute clear system arp table

Backup Configuration

# exec backup config tftp conf/test-fw-01_20180913.conf 192.168.0.10

Displaying logs via CLI

Check log filter

# execute log filter dump
category: traffic
deice: memory
(snipp)
Filter:
(snipp)

set filter

# execute log filter device    <- Check Option
Example output (can be different if disk logging is available):
Available devices:
0: memory
1: disk
2: fortianalyzer
3: forticloud

# execute log filter device XX   <- Set Option

# execute log filter category    <- Check Option
 0: traffic
 1: event
 2: utm-virus
 3: utm-webfilter
 4: utm-ips
 5: utm-emailfilter
 7: utm-anomaly
 8: utm-voip
 9: utm-dlp
10: utm-app-ctrl
12: utm-waf
15: utm-dns
16: utm-ssh
17: utm-ssl
18: utm-cifs
19: utm-file-filter
# execute log filter category XXXX   <- Set Option

Example

# execute log filter device 1       <- 1: disk
# execute log filter category 1     <- 1: event

View log

# execute log display

config system interface

edit "port1"

set vdom "root"

set mode dhcp

set allowaccess ping https ssh snmp http

set type physical

set lldp-reception enable

set role wan

set snmp-index 1

edit "port2"

set vdom "root"

set mode static

set ip 10.0.0.1 255.255.255.0

set type physical

set snmp-index 2

config system ha

set group-name "HAGroup"

set mode a-p

set password Fortinet

set hbdev "ha" 50 "port14" 0

set session-pickup enable

set override disable

set priority 180

end

On the Slave Fortigate

config system ha

set group-name "HAGroup"

set mode a-p set password Fortinet

set hbdev "ha" 50 "port14" 0

set session-pickup enable

set override disable

set priority 125

end

config user tacacs+

edit "TACACS-SERVER"

set server <IP address>

set key <string>

set authen-type ascii

set source-ip <IP address>

config log tacacs+accounting setting
set status enable set server "10.1.100.34"
set server-key ************ end
config log tacacs+accounting filter
set login-audit enable
set config-change-audit enable
set cli-cmd-audit enable
end
